DC DC Converter 24V to 12V Power Converter 20Amp Factory price
SWITCHMODE:
1. Input Polarity reverse: Diode Protection
2. Output Polarity reverse: Circuit Protection
3. Output Short: Circuit Protection
4. Over Heating: Circuit Protection
5. Over Load: Circuit Protection
DC to DC converter | ||||||||
P/No. | PV2412-6 | PV2412-10 | PV2412-20 | PV2412-30 | PV2412-40 | PV2412-50 | PV2412-60 | PV2412-100 |
Input voltage | 20-30V | |||||||
Output voltage | 12-13.8V | |||||||
Output power | 6 Amp (continuous) | 10 Amp (continuous) | 20 Amp (continuous) | 30Amp (continuous) | 40Amp (continuous) | 50 Amp (continuous) | 60; Amp (continuous) | 100 Amp (continuous) |
Output power | ;10 Amp(Max) | 15 Amp(Max) | 30 Amp(Max) | 45 Amp(Max) | 60 Amp(Max) | 70 Amp(Max) | 80 Amp(Max) | 130 Amp(Max) |
Standby current | ≤15 mA | ≤20 mA | ≤70 mA | ;≤80 mA | ≤80 mA | ≤90 mA | ≤90 mA | ≤110 mA |
Input fuse | 7.5A | 10A | 20A | 30A | 40A | 2*30A | 2*40A | 4*30A |
Efficiency | 85%~90% | |||||||
Thermal protection | 65°C±5°C | |||||||
Connection cable | ;1.5mm2/900mm | 2.0mm2/900mm | 2.5mm2/900mm | 4.0mm2/900mm | 6.0mm2/900mm | 10mm2/900mm | 12mm2/900mm | ;20mm2/900mm |
Fuse location input | Internal | External | Internal | |||||
Cooling fan | No | Automatic temperature controlled | ||||||
Input polarity reverse | Diode protection | |||||||
Output polarity reverse | Circuit protection | |||||||
Output short | Circuit protection | |||||||
Over heating | Circuit protection | |||||||
Over load | Circuit protection | |||||||
Dimension(L*W*H) | 88*87*42mm | 126*87*42mm | 182*115*62mm | 222*115*62mm | 222*115*62mm | 275*165*79mm | 275*165*79mm | 365*165*79mm |
Weight(KG) | 0.35 | 0.45 | 0.8 | 0.95 | 1.0 | 2.0 | 2.0 | 3.03 |
1. Cargo carton or depends on customer’s request.
2. 40-45 working days upon the receipt of deposit
Why choose us:
l- The good construction warranty-1 years
l- Your client satisfied on the right schedule and quality
l- Your can get good reputation from your market and obtain more orders
l- Our professional service before and after sale
l- The reasonable price
1.Designed to electric vehicle;
2.Also could customize it;
3.High quality and low price converters for you choose.
l- Any questions from you are welcome and will be replied in 24 hours.
